RCF PL68-EN. Passive 24W 6" Coaxial Ceiling Speaker with Fire Dome (White).
Technical Specifications
| Acoustical specifications | |
| Frequency Response (-10dB) | 230 Hz - 20000 Hz |
| Max SPL @ 1m | 102 dB |
| Max SPL @ 4m | 90 dB |
| Coverage angle | 126° |
| System Sensitivity | 94 dB |
| System Sensitivity 1W @ 4m | 82 dB |
| Power section | |
| Amplification | Full Range |
| Power Handling | 6 W |
| Peak Power Handling | 24 W PEAK |
| Protections | Thermal fuse |
| Recommended Amplifiers | DXT 3000, DXT 4000, DXT 7000 |
| Transducers | |
| Fullrange | 1 x 6.0'' |
| Input/Output section | |
| Input connectors | Ceramic screw terminals |
| Output connectors | Ceramic screw terminals |
| Constant Voltage Transformer | 100 V |
| Power selection 1 | 6 W - 1667 ohm |
| Power selection 2 | 3 W - 3333 ohm |
| Power selection 3 | 1.5 W - 6667 ohm |
| Standard compliance | |
| Safety agency | CE compliant |
| EN54-24 certified | Yes |
| CPR number | 1488-CPR-0486/W |
| Physical specifications | |
| Cabinet/Case Material | Metal |
| Hardware | Steel back cover |
| Grille | Steel |
| Color | White - RAL 9003 |
| Size / Weight | |
| Depth | 91 mm / 3.58 inches |
| Recessed Depth | 90 mm / 3.54 inches |
| Diameter | 220 mm / 8.66 inches |
| Cut out diameter | 200 mm / 7.87 inches |
| Weight | 1.12 kg / 2.47 lbs |
| Shipping information | |
| Package Height | 120 mm / 4.72 inches |
| Package Width | 230 mm / 9.06 inches |
| Package Depth | 230 mm / 9.06 inches |
| Package Weight | 1.6 kg / 3.53 lbs |
