AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes

AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes

$1,597.00
$1,597.00
Skip to product information
AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes
  • AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes
  • AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes
  • AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes
  • AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes
AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes

AKG CS3 BU, Conference System Equipment, All in one conference controller, For discussion systems of up to 60 stations per base unit, Four selectable operating modes

$1,597.00
$1,597.00

The CS3 BU is the base unit for the CS3 conference system and provides all the necessary inputs and outputs to manage a conference for up to 60 microphone stations. It is the interface to all audio devices in a meeting room and offers a RS232 interface to connect an optional camera control system. The CS3 BU can even work in a stand-alone mode in four selectable operating modes offering maximum flexibility in conference management. With the NOM limitation function, the maximum number of active stations can be programmed to 1, 2, 4 or 6 simultaneous open microphones.

Features

  • All in one conference controller
  • For discussion systems of up to 60 stations per base unit
  • Four selectable operating modes
  • For flexible conference management
  • Connects to all relevant devices
  • e.g. PA, recording, ext. audio and camera control systems
  • Compact 19" housing
  • For easy rack mounting

Specifications

  • Power Supply: SMPS 100-240V (50Hz / 60 Hz) 3A
  • Static Consumption: 13W
  • Nominal Power Consumption: 320W
  • Output Power: ≤90W / 24V each way
  • Mode: Balanced / Unbalanced
  • Frequency Response: 50Hz-20kHz
  • S/N: >80dB
  • Harmonic Distortion: <0.5%
  • Harmonic Distortion at Overload: <1%
  • Crosstalk Attenuation (1kHz): >50dB
  • Operating Temperature: 0°C - 40°C at 95% relative humidity (non-condensing)
  • Length: 482 mm
  • Width: 281 mm
  • Height: 88.4 mm
  • Weight: 5.2kg
